VersaUV LEC2-330/640 Specifications

LEC2-330 LEC2-640
Printing method Piezo ink-jet method
Media Width 182 to 762 mm (7.2 to 30 in.)  210 to 1,625 mm (8.3 to 64 in.)
Thickness Max. 1.0 mm (39 mil) with liner for printing.
Max. 0.4 mm (16 mil) with liner and 0.22 mm (9 mil) without liner, for cutting
Roll outer diameter Max. 210 mm (8.3 in.)
Roll weight Max. 25 kg (55 lb.) Max. 40 kg (88.2 lb.)
Core diameter1  76.2 mm (3 in.) or 50.8 mm (2 in.)
Printing / cutting width 2
Max. 736 mm (29 in.)
 Max. 1600 mm (63 in.)
Type ECO-UV (EUV5) 220 ml cartridge (White and decal primer)
ECO-UV (EUV5) 500ml cartridge (cyan, magenta, yellow, black, orange, red, gloss and primer)
Colours 8 colours; (CMYK, Or, Re, Wh and Gl)
7 colours; (CMYK, Or, Re and Wh x2)
7 colours; (CMYK, Or, Re and Wh) and Pr
7 colours; CMYK, Re, Wh and Gl) and Pr
Decal solution; (CMYK, Wh and Gl x2) and Decal Pr
Six colours; (CMYK, Wh x 2 and Gl) and Pr
Six colours; (CMYK, Wh x 2 and Gl x 2)
Four colours; (CMYK x 2)
Stretch solution; EUVS (CMYK and Wh) with EUV5 (Re, Or and Gl)
Stretch solution; EUVS (Wh) with EUV5 (CMYK, Re, Or and Gl)
Stretch solution; EUVS (CMYK and Wh) with EUV5 (Re, Pr and Gl)
Stretch solution; EUVS (Wh) with EUV5 (CMYK, Re, Pr and Gl)
Ink curing unit
Built-in UV-LED lamp
Print resolution (dots per inch)  Max. 1440 dpi
Cutting speed  10 to 300 mm/s (0.4 to 11.8 in/s)
Blade force 3 30 to 500 gf
Blade   Type

Roland CAMM-1 series blade

Offset 0.000 to 1.500 mm (0.0 to 59.1 mil)
Software resolution (when cutting) 0.025 mm/step (0.98 mil/step)
Distance accuracy (when printing) (4) (5) Error of less than ±0.3% of distance travelled or ±0.3 mm (±11.8 mil), whichever is greater
Distance accuracy (when cutting) (4)

Error of less than ±0.4% of distance travelled or ±0.3 mm (±11.8 mil), whichever is greater. When distance correction has been performed (when the setting for [CUTTING MENU] - [CALIBRATION] has been made): Error of less than ±0.2% of distance travelled or ±0.1 mm (±3.9 mil), whichever is greater.

Repeatability (when cutting) (4) (6) ±0.1 mm (±3.9 mil) or less
Alignment accuracy for printing and cutting (4) (7) ±0.5 mm (±19.7 mil) or less
Alignment accuracy for printing and cutting when reloading media (4) (8) Error of less than ±0.5% of distance travelled, or ±3 mm (±0.2 in.), whichever is greater
Connectivity Ethernet (10BASE-T/100BASE-TX, automatic switching)
Power-saving function Automatic sleep feature
Power requirements AC 100 to 240 V ±10%, 3.0 A, 50/60 Hz
AC 100 to 240 V±10%, 3.2 A, 50/60 Hz
Power consumption During operation  Approx. 290 W
Sleep mode 40 W
Acoustic noise level During operation
63 dB (A) or less
During standby  53 dB (A) or less
Dimensions (with stand)  1945 (W) × 781 (D) × 1316 (H) mm (77 [W] x 31 [D] x 52 [h] in.)
2,819 (W) × 781 (D) × 1,316 (H) mm (111 [W] × 31 [D] × 52 [H] in.)
Weight (with stand) 125 kg (275.6 lb.)
163 kg (359.3 lb.)
Environment During operation Temperature: 15 to 32°C (59 to 90°F), humidity: 20 to 80%RH (no condensation)
During standby Temperature: 5 to 40°C (41 to 104°F), humidity: 20 to 80%RH (no condensation)
Included items VersaWorks 6 RIP Software, Roland DG Printer Status Monitor, dedicated stand, power cable, blade, blade holder, media clamps, media holders, replacement blade for separating knife, cleaning liquid, drain bottle, user's manual etc.

Specifications, designs and dimensions listed may be subject to change without notice
1 The media holders of this machine are designed to be used exclusively with media that has a paper tube (core) with an inner diameter of 76.2 mm (3 in.). To use 50.8 mm (2 in.) media, the optional media flanges are required.

2 The length of printing or cutting is subject to the limitations of the program.
3 500 gf is the maximum instantaneous blade force. The blade force must be adjusted according to details such as the media thickness.
4 Media type: Media specified by Roland DG Corporation. Temperature: 25°C (77°F), humidity: 50%RH. Roll media must be loaded correctly. Applicable when all pinch rollers that can be used with the media width are used. Side margins: 25 mm (1.0 in.) or more for both the left and right margins. Excluding expansion/contraction of the media. Assumes all correction and adjustment functions of the machine have been used properly.
5 Print travel: 1 m (39.4 in.)
6 [PREFEED] menu item must be set to "ENABLE." Range for assured repetition accuracy. For media with a width exceeding 610 mm (24 in.): Length: 4000 mm (157.5 in.). For media with a width of 610 mm (24.0 in.) or less: Length: 8000 mm (315 in.)
7 Provided that the media feed length is 3000 mm (118.1 in.) or less. Excludes the effects of slanted movement and of expansion and contraction of the media.
8 Data size: 1625 mm model: 1000 mm (39.4 in.) in the media-feed direction, 736 mm (29 in.) in the carriage-movement direction. No lamination. Automatic detection of crop marks at 4 points when media is reloaded. During cutting, [PREFEED] menu item must be set to "ENABLE." Excluding possible shift caused by expansion/contraction of the media and/or by reloading the media.

 VersaWorks 6 System Requirements
Operating system Windows® 10 (32/64-bit), Windows® 8.1 (32/64-bit),
Windows® 7 Professional / Ultimate (32/64-bit)
CPU Intel® Core™2 Duo, 2.0 GHz or faster recommended
RAM 2 GB or more recommended
Video card and monitor A resolution of 1280 x 1024 or more recommended
Free disk space (HDD/SSD) 40 GB or more recommended
Hard-disk file system NTFS format
Other Internet connection recommended


Code Description
EUV5-5CY ECO-UV Ink Cyan, 500 cc
ECO-UV Ink Magenta, 500 cc
ECO-UV Ink Yellow, 500 cc
EUV5-5BK ECO-UV Ink Black, 500 cc
ECO-UV Ink Orange, 500 cc
EUV5-5RE ECO-UV Ink Red, 500 cc
EUV5-WH ECO-UV Ink White, 220 cc
EUV5-5GL ECO-UV Ink Gloss, 500 cc
ECO-UV Primer, 500 cc
Decal Primer, 220 cc
CMYK + White, 220 ml


Code Description
SL-CL Cleaning liquid, 220 cc
BOFA L204448202 Air purification unit
ZEC-U5032 Blades for sign vinyl, fluorescent and reflective film, 2pcs
Blades for thicker material like sandblast, cardboard or thick vinyl, 5pcs
Blade holders - Resin blade holder with blade depth adjustment
XD-CH4  Blade holders - Adjustable depth blade holder, Alloy tip - Blue, Orange, Red
Automated Take-Up System for LEC2-330
TU4-64 Automated Take-Up System for LEC2-640
ET-30* Extension Table for LEC2-330
ET-64 Extension Table for LEC2-640
TB-30* Tension Bar for LEC2-330
*TB-30 and ET-30 cannot be used at the same time.

  • The Extension Table, ET-30 can help create cardboard packaging or control panels. LEC2-330 in combination with ET-30 can feed* materials between 200g and 300g with a media thickness around 0.25 – 0.40 mm, and the maximum size of 636 x 939 mm.

* Pre-testing is recommended before use.

  • The Tension Bar, TB-30* can be used to print on thin film used for flexible packaging media such as OPP or PET film. TU4-30 is required with TB-30 in order to function correctly.
    Feedable media specification:**
    - media thickness between 30μm and 50μm
    - media width between 688 and 762mm
    - media with anti-static treatment
    - corona treatment*** on print surface

*You cannot cut, or do any operation that requires back-feeding of the media when printing with the TB-30.
** The correct media feeding is affected by several conditions, for that reason pre-testing is required before actual use.
*** Corona treatment; surface modification method to change properties on surface by corona discharge plasma. This improves printing characteristics such as wettability.
