Can Do.

TrueVIS VG3-640,
VG3-540
Large-Format Inkjet Printer/Cutters

TrueVIS, the all-in-one solution that has transformed thousands of businesses worldwide, is now entering a new stage of evolution for the digital age. Elevate your company with a winning partnership and grow your business with confidence.

  • Intuitive and user-friendly operation
  • Premium print and excellent colour options
  • Flexible and customisable workflows
  • Future-proof and reliable support

Everything You Need to Succeed

TrueVIS VG3 Printer/Cutter

Choose from a variety of sizes to suit your business

TrueVIS TR2 Ink

Get stunning results every time with our economical TR2 ink

VersaWorks 6 RIP

Power your workflow with our most intelligent RIP software to date

Roland DG Care Warranty

Secure your investment with industry-leading support

VG3 540
VG3-540
VG3 640
VG3-640
SIZES
54"
SIZES
64"
CONTROL PANEL
7" LCD Touch
INK CONFIGURATIONS
Dual CMYK
CMYKLcLmOrGr
CMMYKLkOrGr
CMYKLkOrGrWh
CMYKLcLmLkWh
CMYKLcLmLkOr

Satisfy Your Customers with Perfect Colour

Whether you need high-speed production or extreme colour accuracy, the TrueVIS VG3 solution is available in the perfect ink configuration for your business. Equipped with rigorously tested and industry certified TR2 inks, you can provide premium-quality prints at competitive prices.

Printed sign in clothes shop
Printed label on bottle
Printed window graphic
Selection of printed and cut stickers
Large printed wall graphic
Van with printed wrap
Selection of custom T-shirts
Printed floor graphic

Visit our Virtual Showroom

Find out how Roland DG equipment can support your business by taking a virtual demo from the comfort of your own device.

See the TrueVIS VG3 in your space

Scan the QR code using your mobile device.

Compatible with Other RIP Providers

Are you already using another RIP solution?

Many RIP software providers support Roland DG printers. Check this compatibility RIP list to see if you can install this Roland DG device into your existing workflow.

The Roland DG Connect app showing on a notebook and a mobile device

Roland DG Connect App
For Everything Creative

Reduce downtime and improve work efficiency with a machine monitoring assistant that helps you gain a detailed understanding of your entire print operation while keeping your device running at optimum performance.

The Roland DG Connect app showing on a notebook and a mobile device
VG3 Series closeup

Do Anything with High-quality Ink

Whether you need high-speed production or extreme colour accuracy, the TrueVIS VG3 solution is available in the perfect ink configuration for your business. Equipped with rigorously tested and industry certified TR2 inks, you can provide premium-quality prints at competitive prices.

  • GREENGUARD Gold certified
  • Avery ICS certified
  • Fast outgassing times
  • Excellent durability





CMYK

Produce a huge range of colours with CMYK ink or double up for even greater productivity

Light Colours

Use Light cyan, Light magenta and Light black for smoother gradients and hyper-real skin tones

High-Opacity White

Print high-opacity white details or add sub-coats for dark or transparent materials

Gamut Extension

Reproduce your customers’ brand colours and more with even greater accuracy



See Specification for Ink Configurations

User-friendly Features

Key benefits


Great Return on Investment
Affordable and powerful, the VG3 Series can quickly generate profits and pay for itself.
Efficient Cutter Integration
Seamlessly pair with a Roland DG cutter for high-intensity production.
Powerful Software Included
VersaWorks 6 included, letting you produce print and cut output in a simple workflow.
The Roland DG Legacy
Make a safe investment with Roland DG’s world-renowned quality and reliability.
Rapid Media Adjustment
Ensure perfect output and optimum settings for each media with automated adjustment.
ICC Profiles
Access Roland DG's library of ICC profiles and find hundreds of profiles to match your needs.


Fast Set-up and Ease of Use
Plug in and start working immediately thanks to Roland DG’s user-friendly interface.
Efficient and Fluid Workflows
Produce your work, your way with flexible job-management features.
Integrated Take-up Unit
Easily produce unattended long print runs with full confidence.
Low Running Cost
Long-life print heads and intelligent management software ensures long life and sustained quality.
Mobile Cost Tracking
Track ink usage and more in real time with the Roland DG Connect mobile app.
Sheet Perforated Cut
Separate individual jobs without cutting the backing sheet enabling unattended long runs and fast finishing.
VersaWorks RIP on computer monitor
VersaWorks RIP on computer monitor

Create Your Perfect Workflow

The TrueVIS VG3 solution comes with our most advanced release of VersaWorks 6 RIP software to date. This fast, flexible and feature-rich system gives you all you need to produce your work, your way.
Flexible Queue Settings
Multiple queues, hot folders and unlimited pre-sets.
Intuitive Interface
Simple, user-friendly drag-and-drop operation.
Rapid Native PDF File Processing
Easy handling and accurate reproduction of transparencies and shadows.
Onboard Cut Line Editing
Add contour cut and perforated cut lines directly within the RIP.

FIND OUT MORE

Separate printer and cutter
Separate printer and cutter

Seamless productivity

Enhance your capabilities and boost your productivity even further by adding our latest GR2 cutter to your workflow. Besides producing long runs of print and cut jobs, you can also simultaneously print on one device whilst cutting on another for intensive production.

Ask your dealer or contact Roland DG for more information.

For the Future

With over 28.000 users worldwide, TrueVIS perfectly embodies Roland DG's long legacy of premium, high-quality print and cut.

FIND OUT MORE

Additional Information

Expand All | Collapse All
TrueVIS VG3 Series
VG3-640 VG3-540
Printing Method Piezo ink-jet method 54 inch
Media Width 335 to 1,625 mm (13.2 to 64 in.) 295 to 1,371 mm (11.7 to 54 in.)
Thickness Max. 1.0 mm (39.3 mil) with liner, for printing
Max. 0.4 mm (15.7 mil) with liner and 0.22 mm (8.6 mil) without liner, for cutting
Roll outer diameter Max. 250 mm (9.8 in.)
Roll weight Max. 45 kg (99 lb.) Max. 35 kg (77 lb.)
Core diameter 76.2 mm (3 in.) or 50.8 mm (2 in.)
Printing/cutting width (*1) Max. 1,600 mm (62.9 in.) Max. 1,346 mm (52.9 in.)
Ink Type TrueVIS INK 500 ml pouch (only white 250 ml)
Colors Eight colors (cyan, magenta, yellow, black, light cyan, light magenta, light black, and white)
Eight colors (cyan, magenta, yellow, black, light cyan, light magenta, light black, and orange)
Eight colors (cyan, magenta, yellow, black, light black, orange, green and white)
Eight colors (cyan, magenta, yellow, black, light cyan, light magenta, orange, and green)
Seven colors (cyan, magenta, yellow, black, light black, orange, and green)
Four colors (cyan, magenta, yellow, and black)
Printing resolution (dots per inch) Max. 1,200 dpi
Cutting speed
10 to 300 mm/s (0.39 to 11.8 in/s)
Blade force (*2) 30 to 500 gf
Blade
Type Roland CAMM-1 series blade
Offset 0.000 to 1.500 mm (0.0 to 59 mil)
Software resolution (when cutting) 0.025 mm/step (0.98 mil/step)
Media heating system (*3) Print heater set temperature: 30 to 45 °C (86 to 113 °F)
Dryer set temperature: 30 to 55 °C (86 to 131 °F)
Connectivity Ethernet (100BASE-TX/1000BASE-T, automatic switching)
Power-saving function Automatic sleep feature
Power requirement 100-120/220-240 Va.c. 50/60 Hz 8.0/4.1 A
Power consumption During operation Approx. 1,090 W
Sleep mode Approx. 50 W
Acoustic noise level During operation 63 dB (A) or less
During standby 53 dB (A) or less
Dimensions (Width x Depth x Height) 2,886 mm × 748 mm × 1,320 mm (113.7 in. x 29.5 in. x 52.0 in.) 2,632 mm × 748 mm × 1,320 mm (103.7 in. x 29.5 in. x 52.0 in.)
Weight 203 kg (448 lb.) 189 kg (417 lb.)
Environment During operation Temperature: 20 to 32 °C (68 to 89.6 °F), humidity: 35 to 80 % RH (no condensation)
Not operating Temperature: 5 to 40 °C (41 to 104 °F), Humidity: 20 to 80 % RH (no condensation)
Included items Dedicated stands, power cord, Media take-up unit, media holders, replacement blade for separating knife, cleaning liquid, drain bottle, User's Manual, Software(VersaWorks, Roland DG Connect), etc.
*1 The length of printing or cutting is subject to the limitations of the program.
*2 500 gf is the maximum instantaneous blade force.
The blade force must be adjusted according to details such as the media thickness.
*3 Warm-up is required after power up. This may require 5 to 20 minutes, depending on the operating environment.
Depending on the ambient temperature and media width, the preset temperature may fail to be reached.
Model Description
TR2-CY TrueVIS INK Cyan, 500 cc
TR2-MG TrueVIS INK Magenta, 500 cc
TR2-YE TrueVIS INK Yellow, 500 cc
TR2-BK TrueVIS INK Black, 500 cc
TR2-LC TrueVIS INK Light cyan, 500 cc
TR2-LM TrueVIS INK Light magenta, 500 cc
TR2-LK TrueVIS INK Light black, 500 cc
TR2-OR TrueVIS INK Orange, 500 cc
 TR2-GR TrueVIS INK Green, 500 cc
TR2-WH TrueVIS INK White, 250 cc
TR2-CL2 TrueVIS Cleaning Liquid, 500 cc
VW-S1 Densitometer tool
ZEC-U5032 Cutting blade for standard sign vinyl, 2pcs.
ZEC-U5025 Cutting blade for standard sign vinyl, reflective and fluorescent / thick media, 5pcs.
XD-CH3 Adjustable blade holder - resin
XD-CH4-BL Adjustable blade holder - black
XD-CH4-OR Adjustable blade holder - orange
XD-CH4-RD Adjustable blade holder – red
DU3-54 Optional Dryer/Blower Unit for VG3-540
DU3-64 Optional Dryer/Blower Unit for VG3-640
Roland DG Care
Roland DG Care

Protect Your Investment

Take your business forward with complete peace of mind thanks to Roland DG’s renowned post-sale service. Roland DG Care warranties cover you for much more than device maintenance.

  • Factory-trained service engineers
  • Quick installation and first-time set-up
  • Expert advice and training
Roland DG Logo
Roland DG Logo

Why Choose Roland DG?

People buy Roland DG equipment because they know it will do what they need it to do - and more. Our mission is to bring new opportunities to society through digital technology, and we aim to develop the most reliable solutions in the industry.

  • More than 40 years of trusted technical excellence.
  • Robust, flexible technology and repeatable results.
  • Unparalleled post-sales service and support.

Get in touch today and find out why Roland DG is the first choice for print businesses worldwide.
