VersaSTUDIO BN-20 Series Specifications

Model BN-20  BN-20A
Printing technology Piezoelectric inkjet
Media Width *1 150 to 515 mm (5.9 to 20.3 in.)
Thickness Max. 1.0 mm (39 mil) with liner, for printing
Max. 0.4 mm (16 mil) with liner and 0.22 mm (9 mil) without liner, for cutting
Roll weight Max. 6 kg (13.2 lb)
Roll outer diameter Max. 150 mm (5.9 in.)
Core diameter 76.2 mm (3 in.) or 50.8 mm (2 in.)
Printing/cutting width *2 Max. 480 mm (18.9 in.)
Ink Type and capacity ECO-SOL MAX/ MAX2/ MAX 3, 220 cc cartridges
 ECO-SOL MAX3, 220 cc cartridges
Colours 5 colours (Cyan, Magenta, Yellow, Black, Metallic Silver or White)   4 colours (Cyan, Magenta, Yellow, Black)
Printing resolution (dots per inch) Max. 1440 dpi
Cutting blade Type Roland CAMM-1 series compatible
Blade Offset 0.25 mm (9 mil)
Cutting speed 10 to 150 mm/s
Blade force 30 to 300 gf
Software resolution (when cutting) 0.025 mm/step
Distance accuracy (when printing) *3,*4 Error of less than ±0.3% of distance travelled, or ±0.3 mm, whichever is greater
Distance accuracy (when cutting) *3,*5 Error of less than ±0.4% of distance travelled, or ±0.3 mm, whichever is greater
Repetition accuracy (When cutting) *3,*6 ±0.1 mm or less
Alignment accuracy for printing and cutting *3,*7 ±0.5 mm or less
Alignment accuracy for printing and cutting when reloading media *3,*8 Error of less than ±0.5% of distance travelled, or ±3 mm, whichever is greater
Print heater *9 Temperature: 35°C (95°F)
Connectivity USB (compliant with Universal Serial Bus Specification Revision 2.0)
Power-saving function Automatic sleep feature
Power requirements AC 100 to 240 V ±10 %, 1.5 A, 50 / 60 HZ
Power consumption During operation Approx. 90 W
Sleep mode Approx. 5.5 W
Acoustic noise level During operation 62 dB (A) or less
During standby 42 dB (A) or less
Dimensions/Weight 1009 (W) x 582 (D) x 293 (H) mm (39.7 x 23 x 11.5 in.) / 36 kg (79.4 lbs)
Environment Power on *10 Temperature: 20 to 32°C (68 to 90°F), humidity: 35 to 80%RH (no condensation)
Power off Temperature: 5 to 40°C (41 to 104°F), humidity: 20 to 80%RH (no condensation)
Included Items Roland VersaWorks 6 RIP Software, power cable, USB cable, blade, blade holder, User's Manual, etc.

VersaWorks 6 System Requirements
Operating System Windows® 10 (32/64 bit), Windows® 8.1 (32/64 bit), Windows® 7 Ultimate/Professional (32/64 bit)
Hard-disk file system  NTFS Format
CPU  Intel Core™ 2 Duo, 2.0 GHz or faster recommended
RAM  2GB or more recommended
Video card and monitor A resolution of 1280 x 1024 or more recommended
Free hard disk space 40 GB or more recommended
Optical drive DVD-ROM
Ethernet Connection  100 mbps
Other  Internet connection recommended

*1 It must be within the ranges: 150 to 170 mm (5.9 to 6.7 in.), 200 to 235 mm (7.9 to 9.3 in.), 287 to 322 mm (11.3 to 12.7 in.), 348 to 383 mm (13.7 to 15.1 in.), 393 to 429 mm (15.5 to 16.9 in.), 439 to 474 mm (17.3 to 18.7 in.), 487 to 515 mm (19.2 to 20.3 in.).

*2 The length of printing or cutting is subject to the limitations of the program.

*3 Media type: Media specified by Roland DG Corp. Temperature: 25°C (77°F), humidity: 50%. Roll media must be loaded correctly. Front margin: 35 mm or more. Excluding expansion/contraction of the media. All correction or adjustment function of this machine has been made properly.

*4 With Roland PET film, print travel: 1 m.

*5 Range for assured repetition accuracy: Length 1000 mm.

*6 Range for assured repetition accuracy: Length 1000 mm.

*7 Provided that media length is under 1000 mm. Excludes the effects of slanted movement and of expansion and contraction of the media.

*8 Data size: 1000 mm in the media-feed direction, 480 mm in the carriage-movement direction. No lamination. Automatic detection of crop marks at 4 points when media is reloaded. Excluding possible shift caused by expansion/contraction of the media and/or by reloading the media.

*9 Warm-up is required after power up. This may require 5 to 20 minutes, depending on the operating environment. Depending on the ambient temperature and media width, the temperature may fail to be reached 35 (°F).

*10 Operating environment.

Specifications, designs and dimensions listed may be subject to change without notice.
