TrueVIS LG & MG UV Printer/Cutters
Combining the flexibility of print and cut, the benefits of UV-LED printing and TrueVIS heritage, the LG and MG series add a new dimension to graphics printing.
- High-definition output
- Speciality printing for textures and effects
- Broad media compatibility
- High density white ink
- Fast drying print for quick turnaround and finishing
Download Brochure:
UV Print and Cut Solutions
"There is no doubt that Roland DG has raised the company’s capabilities in the UV roll-to-roll market and that the LG series will be a formidable competitor."
Take Print and Cut Further
TrueVIS is synonymous with industry-beating print and cut machines. Enhance your capabilities with the added power of premium-quality UV-LED printing technology and speciality effects capabilities, and offer your customers even more products.
Frequently Asked Questions
What are the Roland DG TrueVIS LG and MG Series designed to do?
The Roland DG TrueVIS LG and MG Series are UV printer/cutters designed for businesses that want to produce a wider range of high-value graphics in-house. They combine printing and contour cutting in a single workflow, with UV-LED ink technology, white ink, gloss effects, and extended colour configurations, depending on the chosen model.
In practical terms, this means a print business can move beyond standard graphics and offer applications such as window graphics, stickers and labels, backlit displays, POP displays, packaging prototypes, decals, short-run signage and textured print effects. The value is not only creative. It is operational too. More work can be produced internally, with less reliance on outsourcing and greater control over quality, timing, and margins.
How do the LG and MG Series help a business expand its applications?
The LG and MG Series give print businesses access to applications that are difficult to produce with standard CMYK printing alone. High-opacity white ink supports printing on transparent, dark or coloured materials. Gloss ink can add texture, raised effects or premium details. Red and Orange inks, where selected, help reproduce stronger brand colours and more vivid graphics.
For a business, this matters because customers rarely ask for “UV technology”. They ask for a window graphic that looks clean from both sides, a label that feels more premium, a prototype that looks closer to the final product, or a display that stands out at close range. The LG and MG Series turn those requests into real production opportunities.
Which businesses are best suited to the TrueVIS MG Series?
The TrueVIS MG Series is a good fit for smaller print businesses, owner-led sign shops, companies moving up from entry-level print and cut, and users familiar with previous Roland VersaUV LEC or LEC2 models who want a more accessible route into UV roll-to-roll production.
MG is especially relevant when the business wants UV versatility, but does not yet need the higher productivity and production features of the LG Series. It suits short-run signage, labels, decals, packaging samples, prototypes and occasional premium-effect work. It can also make sense for businesses that want to reduce outsourcing and test new services without moving to a higher-volume platform immediately.
The MG series is the more approachable UV print-and-cut option for businesses that need flexibility, professional output, and a manageable investment.
Which businesses are best suited to the TrueVIS LG Series?
The TrueVIS LG Series is the stronger choice for busier sign shops, print service providers and production-focused environments where volume, deadlines and repeatability matter every day. It is designed for businesses that already handle a steady flow of work, or want to take on more without making production feel fragile.
LG is better suited when the business needs faster output, easier day-to-day operation, larger ink capacity, integrated take-up for longer runs, automatic calibration support and more productive multilayer printing. This is where LG becomes more than a UV printer/cutter. It becomes a production tool for businesses that need quality and speed to work together.
How does UV print and cut improve turnaround time?
UV-LED printing cures the ink during the printing process, so printed graphics can move more quickly into cutting, finishing or delivery. That can make a real difference when customers expect short lead times or when a shop has to manage many small jobs on the same day.
This is not just about printing faster. It is about reducing the waiting time between steps. For applications such as stickers, window graphics, POP displays, packaging prototypes or short-run promotional work, that shorter workflow can help a business respond faster, keep more jobs moving and avoid losing time in the gaps between production stages.
Why is the LG Series particularly strong for productive environments?
The LG Series combines several features that matter in real production: staggered printheads, powerful UV-LED lamps, 750 ml ink pouches, a 7-inch touchscreen, automatic calibration, an integrated take-up unit and one-pass multilayer printing. Taken separately, these are technical features. Together, they reduce the time operators spend preparing, checking, correcting, and restarting work.
That is the benefit a production manager or business owner will recognise. The machine helps keep work moving. It supports longer runs. It reduces friction during setup. It gives the operator clearer information. It makes complex UV work, including layered print with white, colour, gloss, more manageable in daily production.
How do VersaWorks and Roland DG Connect support day-to-day reliability?
The LG and MG Series are part of a wider Roland DG workflow, not just standalone UV printers/cutters. VersaWorks provides the RIP environment for preparing and managing print and cut jobs, including colour management, special colour workflows and production settings for UV applications. Roland DG Connect adds another layer of control by helping users monitor printer status, production activity and maintenance-related information. It can also support cost and production analysis, helping businesses better understand expenses and make more informed decisions about job value and profitability. For roll-to-roll visual communication work, Roland DG Connect Designer with the Visual Communication module can help operators prepare print-and-cut graphics more efficiently, with tools for contour cutting, white-ink setup, background removal, and advanced print preparation.
For a print business, the benefit is practical. The team can prepare jobs, monitor production and understand business performance with greater confidence. That helps reduce uncertainty, protect margins and keep daily work under control.
Everything You Need to Succeed
Choose from a variety of models and sizes to suit your business.
Power your workflow with our most intelligent engine yet
Get stunning results every time with economical Eco UV ink
Secure your investment with industry-leading support

Ultimate Print Expression
The combination of ultra high-definition print technology and specially formulated UV ink lets you accurately reproduce colours in a wide colour gamut.
Certifications
GREENGUARD Gold
ECO-UV5 inks are GREENGUARD Gold certified, meaning they meet strict standards of low chemical emissions making them ideal for indoor applications.
LG SeriesHigh-performance Features
MG SeriesCustom Professional Features
Roland DG Connect App
For Everything Creative
Reduce downtime and improve work efficiency with a machine monitoring assistant that helps you gain a detailed understanding of your entire print operation while keeping your device running at optimum performance.
Key benefits
|
Great Return on Investment Affordable and powerful, the LG and MG Series can generate profits and pay for itself quickly. |
|
| Powerful Software Included VersaWorks included, letting you produce print and cut output in a simple workflow. |
|
|
Priced to Suit Your Business Roland DG UV print and cut solutions are available to fit any budget. |
|
|
Sheet Perforated Cut Separate individual jobs without cutting the backing sheet enabling unattended long runs. |
|
|
Efficient and Fluid Workflows Produce your work, your way with flexible job-management features. |
|
|
Professional Colour Management Match your customers' colour with ease thanks to advanced RIP features. |
|
|
Fast Set-up and Ease of Use Plug in and start working immediately thanks to Roland DG’s user-friendly interface. |
|
|
The Roland DG Legacy Make a safe investment with Roland DG’s world-renowned quality and reliability. |
|
|
Low Running Cost Long-life print heads and ink-clogging prevention ensures long life and sustained quality. |
|
|
Texture Libraries Add extra expression to your prints easily with a library full of exciting printable textures. |
|
|
Mobile Cost Tracking Track ink usage and more in real time with the Roland DG Connect mobile app. |
|
|
ICC Profiles Access Roland DG's library of ICC profiles and find hundreds of profiles to match your needs. |
For the Future
With over 28.000 users worldwide, TrueVIS perfectly embodies
Specifications
| Model | LG-640 | LG-540 | LG-300 | ||||
| Printing method | Piezo ink-jet method | ||||||
| Media | Width | 335 to 1625 mm |
295 to 1371 mm |
182 to 762 mm |
|||
| Thickness |
Max. 1.0 mm (39.3 mil) with liner, for printing Max. 0.4 mm (15.7 mil) with liner and 0.22 mm (8.6 mil) without liner, for cutting |
||||||
| Roll outer diameter | Max. 250 mm (9.8 in.) |
||||||
| Roll weight | Max. 45 kg (99 lb.) | Max. 35 kg (77 lb.) | Max. 30 kg (66 lb.) | ||||
| Core diameter | 76.2 mm (3 in.) or 50.8 mm (2 in.) | ||||||
| Printing / cutting width 1 | Max. 1600 mm (62.9 in.) | Max. 1346 mm (52.9 in.) | Max. 736 mm (28.9 in.) | ||||
| Ink |
Type | ECO-UV (EUV5P) 750ml pouch | |||||
| Colours | Eight colours (Cyan, Magenta, Yellow, Black, Gloss, White, Orange, and Red) Seven colours (Cyan, Magenta, Yellow, Black, Gloss, White, and Red) and Primer Seven colours (Cyan, Magenta, Yellow, Black, White, Orange, and Red) and Primer Seven colours (Cyan, Magenta, Yellow, Black, White, Orange, and Red) Six colours (Cyan, Magenta, Yellow, Black, Gloss, and White) and Primer Six colours (Cyan, Magenta, Yellow, Black, Gloss, and White) Four colours (Cyan, Magenta, Yellow, and Black) |
||||||
| Ink curing unit | Built-in UV-LED lamp | ||||||
| Print resolution (dots per inch) | Max. 1200 dpi | ||||||
| Cutting speed | 10 to 300 mm/s |
||||||
| Blade force 2 | 30 to 500 gf | ||||||
| Blade | Type | Roland CAMM-1 series blade | |||||
| Offset | 0 to 1.500 mm (0 to 59 mil) | ||||||
| Software resolution (when cutting) | 0.025 mm/step (0.98 mil/step) | ||||||
| Media heating system 3 | Front heater set temperature: 30 to 55 ℃ (86 to 131 °F) | ||||||
| Connectivity | Ethernet (100BASE-TX/1000BASE-T, automatic switching) | ||||||
| Power-saving function | Automatic sleep feature | ||||||
| Power requirements | 100-120/220-240 Va.c. 50/60 Hz 6.5/3.2 A | 100-120/220-240 Va.c. 50/60 Hz 6.5/3.2 A | 100-120/220-240 Va.c. 50/60 Hz 5.7/2.6 A | ||||
| Power consumption | During operation | Approx. 800 W | Approx. 800 W | Approx. 650 W | |||
| Sleep mode | Approx. 85 W | ||||||
| Acoustic noise level | During operation |
63 dB (A) or less | |||||
| During standby | 58 dB (A) or less | ||||||
| Dimensions (with stand) | 2902 mm x 748 mm x 1412 mm |
2648 mm x 748 mm x 1412 mm |
2038 mm x 748 mm x 1412 mm |
||||
| Weight (with stand) | 209 kg (461 lb.) | 198 kg (437 lb.) | 168 kg (371 lb.) | ||||
| Environment | During operation 4 | Temperature : 20 to 32 ℃ (68 to 89.6 °F), Humidity: 35 to 80 % RH (no condensation) | |||||
| Not operating | Temperature : 5 to 40 ℃ (41 to 104 °F), Humidity: 20 to 80 % RH (no condensation) | ||||||
Depending on the ambient temperature and media width, the preset temperature may fail to be reached.
| Extension Table | ET-30L | ET-54L | ET-64L | |||
| Model | LG-300 | LG-540 | LG-640 | |||
| Media | Weight | 200 to 300 g/m² (Paperboard such as coated cardboard) | ||||
| Thickness | Max. 1.0 mm | |||||
| Width | 182 to 728 mm |
295 to 1,337 mm | 335 to 1,591 mm | |||
| Length | Max. 1,100 mm | |||||
| Printing/Cutting | Width | Max. 703 mm | Max 1,312 mm | Max 1,566 mm | ||
| Length | Max. 810 mm | |||||
| Blade | ZEC-U3050, ZEC-U3075 | |||||
| Model | MG-640 | MG-300 | |||||
| Printing method | Piezo ink-jet method | ||||||
| Media | Width | 210 to 1625 mm |
182 to 762 mm |
||||
| Thickness |
Max. 1.0 mm (39.3 mil) with liner, for printing Max. 0.4 mm (15.7 mil) with liner and 0.22 mm (8.6 mil) without liner, for cutting |
||||||
| Roll outer diameter | Max. 210 mm (8.2 in.) |
||||||
| Roll weight | Max. 40 kg (88 lb.) | Max. 25 kg (55 lb.) | |||||
| Core diameter | 76.2 mm (3 in.) or 50.8 mm (2 in.) | ||||||
| Printing / cutting width 1 | Max. 1600 mm (62.9 in.) | Max. 736 mm (28.9 in.) | |||||
| Ink |
Type |
ECO-UV (EUV5) 220 ml cartridge (white) ECO-UVS 220 ml cartridge (cyan, magenta, yellow, black, white) ECO-UV (EUV5) 500 ml cartridge (cyan, magenta, yellow, black, red, orange, gloss, primer) |
|||||
| Colours |
Eight colours (cyan, magenta, yellow, black, red, orange, white, gloss) Seven colours (cyan, magenta, yellow, black, red, orange, white) Seven colours(cyan, magenta, yellow, black, red, orange, white) and primer Seven colours(cyan, magenta, yellow, black, red, white, gloss) and primer Six colours(cyan, magenta, yellow, black, white, gloss) and primer Six colours(cyan, magenta, yellow, black, white, gloss) Four colours(cyan, magenta, yellow, black) Shrink solution; EUVS (CMYK and Wh) with EUV5 (Re, Or and Gl) Shrink solution; EUVS (Wh) with EUV5 (CMYK, Re, Or and Gl) Shrink solution; EUVS (CMYK and Wh) with EUV5 (Re, Pr and Gl) Shrink solution; EUVS (Wh) with EUV5 (CMYK, Re, Pr and Gl) |
||||||
| Ink curing unit | Built-in UV-LED lamp | ||||||
| Print resolution (dots per inch) | Max. 1440 dpi | ||||||
| Cutting speed | 10 to 300 mm/s |
||||||
| Blade force 2 | 30 to 500 gf | ||||||
| Blade | Type | Roland CAMM-1 series blade | |||||
| Offset | 0 to 1.500 mm (0 to 59 mil) | ||||||
| Software resolution (when cutting) | 0.025 mm/step (0.98 mil/step) | ||||||
| Connectivity | Ethernet (100BASE-TX/1000BASE-T, automatic switching) | ||||||
| Power-saving function | Automatic sleep feature | ||||||
| Power requirements | 100-240 Va.c. 50/60Hz 2.8 A | 100-240 Va.c. 50/60Hz 2.7 A | |||||
| Power consumption | During operation | Approx. 250 W | Approx. 240 W | ||||
| Sleep mode | 40 W | ||||||
| Acoustic noise level | During operation |
63 dB (A) or less | |||||
| During standby | 53 dB (A) or less | ||||||
| Dimensions (with stand) | 2819 (W) x 781 (D) x 1316 (H) mm |
1945 (W) x 781 (D) x 1316 (H) mm |
|||||
| Weight (with stand) | 163 kg (360 lb.) | 125 kg (276 lb.) | |||||
| Environment | During operation 3 | Temperature: 15 to 32 °C (59 to 89.6 °F), fumidity: 20 to 80 %RH (no condensation) | |||||
| Not operating | Temperature : 5 to 40 °C (41 to 104 °F), Humidity: 20 to 80 % RH (no condensation) | ||||||

| Extension Table
|
ET-30 | ET-64 |
||||
| Model | MG-300 | MG-640 | ||||
| Media |
Paper Weight (thickness) | Approx. 200 to 300 g/m² (0.25 to 0.40 mm) (Paperboard such as coated cardboard) |
||||
Dimensions |
Max. | Max. | ||||
| 545 × 788 mm |
1,091 × 788 mm | |||||
| 800 × 550 mm | 800 × 1,100 mm | |||||
| 636 × 939 mm | ||||||
| ZEC-U3050, ZEC-U3075 | ||||||
| Blade | ||||||
